Product Description

Blue Sea Systems HD Series Battery Switch Single Circuit ON/OFFFeatures: Meets American Boat and Yacht Council (ABYC) requirements for battery switches; UL Listed - UL 1107 electric power switches; Meets UL 1500 and SAE J1171 external ignition protection requirements; Ignition protected - safe for installation aboard gasoline powered boats; Case design allows surface or rear panel mounting; Accepts two 4/0 AWG (95mm2) battery cables; Cranking Rating: 10 sec. 2,750 Amps; Intermittent Rating: 5 min. 900 Amps; Rating 600 Amps; Maximum Voltage Rating 32 Volts DC; Terminal Stud Size 1/2" (M12); Terminal Stud Torque 220 in-lb (24.86 Nm) max.; Mounting Holes Accept 1/4" (M6) Screw; Cable Size to Meet Ratings 4/0 AWG (95mm2); Cable Quantity to Meet Ratings Two Cables; Cable Clearance For 4/0 AWG Cables 1.10" (27.9mm); Weight Lb (Kg) 1.30 (0.59); Click to Download Blue Sea's Battery Management Wiring Schematics

Blue Sea Battery Switch HD Series Single Circuit ON-OFF

$101.59
In Stock at Wholesale Marine
Price checked 6 days ago
Buy Now at Wholesale Marine
Secure checkout Easy returns
or compare prices

Key specs

Sold at Wholesale Marine, $101.59 at the last check on Nov 15, 2026.

Price checked Nov 15, 2026
Price tracked since Oct 9, 2026
Brand Blue Seas
