Marin Quake Bike The Bike Park Gets Serious Gravity riders who have been beating up their trail or enduro bikes at the park know the difference a purpose-built DH bike makes. The Quake is exactly that, a dedicated downhill machine with a Series 4 aluminum frame running the Multi Trac 2 LT suspension platform, which moves the rear pivots from the seatstay to the chainstay. That change matters. It reduces anti-rise so the chassis stays controlled under hard braking, delivers more mid-stroke support, and gives you better feel when bottoming out on the biggest hits. The Flip chips let you tune BB height and chainstay length to your preferred setup, and the seatstay chips can be repositioned to run a 29" rear wheel if that's your preference. The build spec matches the frame's intentions. A Rock Shox Boxxer fork up front handles 200mm of travel, and the Rock Shox Vivid Coil Ultimate DH shock out back delivers hydraulic bottom-out control with adjustable high and low speed compression damping. The SRAM GX DH 7-speed handles shifting duties with the tight cassette range that gravity riding demands. SRAM Maven Bronze four-piston brakes with 200mm HS2 rotors give you the stopping power to carry speed into the park's gnarliest sections. Maxxis DH-rated rubber and SRAM's Descendant crankset, bar, and direct-mount stem keep the parts spec dialed all the way to the contact points. The 56ZS zero-stack headtube opens the door to aftermarket headset options if you want to fine tune your reach or head angle down the road. Features Series 4 aluminum frame with Multi Trac 2 LT suspension platform moves pivots to the chainstay for reduced anti-rise, better braking control, and improved bottom-out feel with 180mm rear travel Integrated flip chips allow chainstay length and BB height adjustment between low BB/long CS (353mm/440mm) and high BB/short CS (361mm/430mm), with seatstay chip repositioning to accommodate a 29" rear wheel Rock Shox Boxxer fork, 200mm travel paired with Rock Shox Vivid Coil Ultimate DH shock with hydraulic bottom-out and adjustable high- and low-speed compression SRAM GX DH 7-speed drivetrain tight-range gravity-specific gearing with SRAM Descendant crankset and direct-mount stem SRAM Maven Bronze four-piston brakes with 200mm HS2 rotors consistent stopping power tuned for DH descents and bike park heat cycles56ZS zero-stack headtube and SRAM UDH-compatible dropout maximize aftermarket headset and direct-mount derailleur upgrade options Specifications Frame Series 4 Aluminum, Multi Trac 2 LT Suspension Platform, 180mm Travel, Adjustable CS Length/BB Height Flip Chips, 27. 5" or 29" Rear Wheel Compatible, 148x12mm Rear Thru-Axle, UDH, Integrated Frame Protection Fork Rock Shox Boxxer 3. 0 RC, 200mm Travel, 29", 110x20mm Maxle Stealth, 52mm Offset Rear Shock Rock Shox Vivid Coil Ultimate DH, 225x75mm Trunnion Upper Mount, 30x M8 Lower Mount, Custom Tune (S: 350 lb/in / M: 450 lb/in / L: 550 lb/in spring rate), Hydraulic Bottom Out, Adjustable High- and Low-Speed Compression Headset FSA No. 74Shifters SRAM GX DH, 7-Speed Front Derailleur N/A (1x drivetrain)Rear Derailleur SRAM GX DH, 7-Speed Crankset SRAM Descendant Alloy, 34T, 165mm Bottom Bracket SRAM DUB BSAChain SRAM PC-1110Cassette SRAM GX DH, 11-15TBrakes SRAM Maven Silver, 4-Piston Hydraulic Disc, HSC 200mm Rotors (Front & Rear)Wheelset Marin DH Rim, Double Wall Alloy, 29mm Inner, Sleeved Joint, Disc Specific, 32H, Tubeless Compatible; Rear Hub: Formula DDL-348S, 148x12mm, 6-Bolt Disc, 32H, Shimano Freehub Body; Front Hub: Marin Forged, 110x20mm, 6-Bolt Disc, 32HTires Front: Schwalbe Magic Mary Gravity Pro, 29x2. 5", Radial, Ultra Soft / Rear: Schwalbe Magic Mary Gravity Pro, 27. 5x2. 5", Radial, Soft Handlebar PNW Range Handlebar, 38mm Rise, 35mm Clamp, 800mm Width Stem Marin Direct Mount Stem, 35mm Length, 35mm Clamp Grips/Bar Tape Marin Grizzly Lock-On Seatpost Marin Alloy, 34. 9mm Saddle Marin Short Nose Intended Use Downhill Note: Components are subject to change without notice. METRICINCHYeti LTSize Small Medium Large A: Seat Tube Length390415430B: Effective Top Tube577599639C: Stack631640640D: Reach420440480E: BB Height355355355F: BB Drop242424G: Head Tube Length100110110H: Head Tube Angle62. 5 deg62. 5 deg62. 5 degI: Seat Tube Angle76 deg76 deg76 degJ: Standover Height-K: Chainstay Length440440440L: Wheelbase122712511291Crank Arm Length165 mm165 mm165 mm Stem Length50 mm50 mm50 mm Handlebar Width800 mm800 mm800 mm Suggested Rider Height Frame Size Small Medium Large Rider Heightcmcmcm Marin Quake Size Small Medium Large A: Seat Tube Length15. 416. 316. 9B: Effective Top Tube22. 723. 625. 2C: Stack24. 825. 225. 2D: Reach16. 517. 318. 9E: BB Height14. 014. 014. 0F: BB Drop0. 90. 90. 9G: Head Tube Length3. 94. 34. 3H: Head Tube Angle62. 5 deg62. 5 deg62. 5 degI: Seat Tube Angle76. 0 deg76. 0 deg76. 0 degJ: Standover Height#VALUE!#VALUE!#VALUE! K: Chainstay Length17. 317. 317. 3L: Wheelbase48. 349. 350. 8Crank Arm Length165 mm165 mm165 mm Stem Length50 mm50 mm50 mm Handlebar Width800 mm800 mm800 mm Suggested Rider Height Frame Size Small Medium Large Rider Heightcmcmcm
